Floor Finishing Machine
Floor Finishing Machine Specification
- Coverage Area
- 36 Square Inch (in2)
- Temperature
- 50 Celsius (oC)
- Noise Level
- 80 db
- Driven Type
- GX160
- Type
- Power Trowel
- Material
- MS
- Capacity
- 280 m3/hr
- Computerized
- No
- Automatic Grade
- Automatic
- Drum Diameter
- 270 Meter (m)
- RotorDiameter
- 270 Meter (m)
- Power
- 5.5 Horsepower (HP)
- Color
- as requested
- Weight
- 95 Kilograms (kg)
- Warranty
- 1 year
Floor Finishing Machine About
This is a SWAN Power Trowel Machine (Concrete Finishing Trowel) used for finishing and smoothing concrete floors after leveling.SWAN Technical Specifications:
-
Engine Type: Petrol Engine (Honda GX160 / 5.5 HP or equivalent)
-
Power Output: 45.5 HP
-
Trowel Diameter: 900 mm (36 inch)
-
Blade Quantity: 4 Blades
-
Blade Size: 345 150 mm
-
Speed: 60120 RPM (variable)
-
Fuel Type: Petrol
-
Weight: 8090 kg
-
Drive Type: Belt Drive
-
Handle: Adjustable foldable handle with throttle control
-
Finish Type: Mirror smooth concrete finishing for floors & slabs
Applications:
Used for industrial flooring, warehouses, concrete slabs, road work, and floor polishing where smooth surface finish is required.
Working Capacity (Approximate):
-
Finishing Area: 30004000 sq.ft per hour (depending on surface condition & operator skill)
-
Trowel Diameter: 900 mm (36 inch)
-
Blade Coverage: 0.64 m per rotation
-
Working Speed: 60120 RPM variable
-
Surface Type: Concrete slabs, floors, industrial sheds, warehouses, roads
